Eddy current - Ansys Maxwell

Hi guys,

I am trying to solve a problem in Ansys Maxwell.

Basically, I want to calculate the eddy current induced in a thin vessel due to an inductor. The current in my inductor varies in time with a specific time-dependent law. It grows up to 200 kA linearly in 20 ms, then it has the flattop for 40 ms and finally, it goes to zero in 20 ms.

I would like to know whether Ansys Maxwell can be useful for these type of problems or it is better to change approach. I was wondering if the time scale is too rapid that the software cannot follow the right dynamics.

I hope in an answer.

Cheers,
Alessio

Comments

  • pblarsenpblarsen Member
    edited August 2019

    Hello,

    Yes, you could use Maxwell Transient if the waveform is just the trapezoidal shape that you described.  The easiest way would be to use a dataset, and to define the excitation expression as "pwl(ds1,time)", where pwl will use the dataset lookup, and time is the simulation time.  20ms is an acceptable time-range for Maxwell, and you would want to use ~2-4ms timesteps so that there are several time-steps up the ramp-up and down the ramp-down.

    If the trapezoidal shape is the varying amplitude of a faster sine-wave, then you might consider choosing one amplitude and using the eddy current solver.

    Remember to use sufficient skin-depth meshing for the induced currents.

     - Paul

  • Aliosha86Aliosha86 Member
    edited August 2019
    Hi Paul,
    Thank you very much for the advice.
    Regarding the mesh I linked the mesh I used for the Magnetostatic simulation in order to have an Adaptative solver.
    Do you think it is good?
  • edited August 2019

    Hi Allessio,

    Magnetostatics does'nt take care of skin depth. It assumes the whole cross section has the same current density. Eddy current meshing on the other hand takes into account the skin depth based on your frequency for meshing.

  • Aliosha86Aliosha86 Member
    edited August 2019

    Hi,

    I attach you a picture of my current profile. As you can see the problem is that I do not have a frequence for my problem. The profile is just trapezoidal and calculating the skin depth is almost impossible.

    I hope this can help you giving me the best advice.

  • Aliosha86Aliosha86 Member
    edited August 2019

    Hi Paul

    I attach you below the profile of the current. As you can see I do not have a frequency to evaluate skin depth for eddy currents.



  • rmagarglrmagargl Austin, TXMember
    edited August 2019

    You could do an FFT on the waveform to see where the current is at the highest harmonics.  In these switching type of waveforms, the highest harmonics come from the edge rate of the signal, not the period, so if you just want a rough number, take the twice the inverse of the rise time as a ballpark characteristic frequency.  You could then use a skin depth mesh operation or a link to an AC eddy current simulation at that frequency.

  • Aliosha86Aliosha86 Member
    edited September 2019

    Thank you, but unfortunately I am not able to use the skin depth mesh operation because it does not work for my geometry and I don't know why.

    I attach you the section of the geometry. I am selecting the surface and use the command but it does not work.
    Cheers,
    Alessio
